Automatic side cable crimping and twisting tinning machine
1.It is a one-ended automatic wire stripping twisting tinning and crimping machine, one side stripping and crimping terminal,
another side stripping and twisting tinning, if you do not need to twist and tin the wire, you can also turn off the twisting
and tinning function in the program.
2. PLC control with touch screen, the stripping length, cutting length, cutting depth, and crimping depth can be set and saved in
PLC touch screens, wires, and terminals are processed carefully and gently during cutting, stripping, and crimping procedures.
3. OTP side-feeding die and straight-feeding die can be used on this machine, if you have a special die, we can change the machine
to fit your die(such as JST, Molex, AMP, and other band die set)
4. High precision servo motor control, low working noise, long life service, and stable performance.
5. this machine can be equipped with a conveyor belt without modifying it to process long wires conveniently.
Automatic side cable crimping and twisting tinning machine, automatic cable stripping crimping and twisting machine
Power: AC220v/50/60hz
Capacity: 4000pcs~5000pcs/h(L=150MM)
Wire range: AWG28#-AWG14#(can be customized)
Cutting length: 45-9999mm(can be customized)
Cutting accuracy: 0.5mm+cutting lengthx0.2%
Stripping length: 0.5-8mm(can be customized)
Pressure: 2.0T
Applicator range: OTP applicator, European applicator, and pneumatic applicator.
Air pressure: 5-6kgf
Size: 965*835*1860
Weight: 280kg
